Standardized Precision Roller Chains
High-quality precision roller chains designed for consistent performance and long service life in demanding applications.
Enquire →Our Products
Automation, Conveyor System, Vibrator Bowl Feeder & Fabrication — manufacturing, exporting and wholesaling industrial material-handling products.
Product Range
Automation, Conveyor System, Vibrator Bowl Feeder & Fabrication — we are involved in manufacturing, exporting and wholesaling a wide array of industrial products. Our range is manufactured using excellent quality raw material in compliance with international quality standards, and is acknowledged for sturdy construction, optimum performance and resistance against corrosion.
Conveyor System
We are involved in the business of manufacturing, exporting and wholesaling a wide array of conveyor products. The range offered by us encompasses Standardized Precision Roller Chains, Designed Special Purpose Conveyor Chain, Slat Band Chains, Flat Belt Conveyor, Trough Conveyors and Flat Food Belts. In addition, customers can avail from us a wide range of Gravity Roller Conveyor, Powered Roller Conveyors, Belt Type Bucket Elevator and many more. These products are manufactured using excellent quality raw material in compliance with international quality standards, and are acknowledged for sturdy construction, optimum performance and resistance against corrosion.
Special Purpose Conveyor Chains
Custom-designed conveyor chains built for specific process requirements and operating conditions.
Enquire →
Slat Band Chains
Durable slat band chains suitable for a wide range of conveying and accumulation applications.
Enquire →
Flat Belt Conveyors
Versatile flat belt conveyor systems for smooth product transfer across production lines.
Enquire →
Trough Conveyors
Trough belt conveyors engineered for bulk material handling with reliable containment and flow.
Enquire →
Flat Food Belts
Food-grade flat belts designed for hygienic conveying in food and beverage processing environments.
Enquire →Conveyor Chain Specifications
Standardized precision roller chains are supplied to common industry standards. Special-purpose and slat-band chains are engineered to application requirements. Final selection depends on load, speed, environment and attachment needs — contact us for exact datasheets.
Precision Roller Chains (Typical ANSI / ISO sizes)
| Chain No. | Pitch | Roller Dia. | Inner Width | Pin Dia. | Min. Tensile Strength* | Typical Use |
|---|---|---|---|---|---|---|
| 40 / 08A | 12.70 mm (0.500") | 7.95 mm | 7.85 mm | 3.96 mm | ≈ 14 kN (3,100 lbf) | Light conveyors, packaging |
| 50 / 10A | 15.875 mm (0.625") | 10.16 mm | 9.40 mm | 5.08 mm | ≈ 22 kN (4,900 lbf) | General industrial conveyors |
| 60 / 12A | 19.05 mm (0.750") | 11.91 mm | 12.57 mm | 5.94 mm | ≈ 31 kN (7,000 lbf) | Heavier conveyors, elevators |
| 80 / 16A | 25.40 mm (1.000") | 15.88 mm | 15.75 mm | 7.92 mm | ≈ 56 kN (12,500 lbf) | Heavy-duty conveying |
| 100 / 20A | 31.75 mm (1.250") | 19.05 mm | 18.90 mm | 9.53 mm | ≈ 87 kN (19,500 lbf) | High-load industrial lines |
| 120 / 24A | 38.10 mm (1.500") | 22.23 mm | 25.22 mm | 11.10 mm | ≈ 125 kN (28,100 lbf) | Very heavy conveying |
* Approximate minimum ultimate tensile strength for standard simplex carbon-steel roller chain (ANSI B29.1 / ISO 606). Actual values depend on grade, manufacturer and series (standard / heavy). Always confirm with the supplied datasheet.
Materials & Options
- • Carbon steel (standard)
- • Heat-treated / high-strength grades
- • Stainless steel (corrosion / food areas)
- • Nickel-plated or coated options
- • Simplex, duplex & multiplex strands
Special Purpose Conveyor Chains
- • Custom pitch & plate geometry
- • Attachment chains (A1, A2, K1, K2, etc.)
- • Extended pins / outboard rollers
- • Double-pitch conveyor series
- • Built to process load & speed data
Slat Band Chains
- • Common widths: ~82.5 / 114 / 190 mm
- • Typical pitch: 25.4 mm (1")
- • Steel or stainless steel top plates
- • Straight-running & side-flex options
- • Suitable for accumulation & packaging
Share your load, speed, centre distance and environment — we will recommend the correct chain and attachments.
Request Chain Datasheet / QuoteRoller Conveyors & Elevators
Customers can avail from us a wide range of Gravity Roller Conveyors, Powered Roller Conveyors, Belt Type Bucket Elevators and related material-handling solutions for industrial lines.
Gravity Roller Conveyors
Cost-effective gravity roller conveyors for manual or incline-based product movement.
Enquire →
Powered Roller Conveyors
Motorized roller conveyor systems for controlled, efficient transport in automated lines.
Enquire →
Belt Type Bucket Elevators
Vertical belt bucket elevators for reliable elevation of bulk materials between process levels.
Enquire →
Vibratory Bowl Feeders
Vibratory bowl feeders are a very common type of parts feeder, and they are a critical part of an automated assembly system. Vibratory bowl feeders move parts around a bowl and into channels in a way that ensures they are perfectly aligned for how the automation system needs them. They make sure parts are continually being presented to the automation system, so that it can perform as designed and maintain a high production rate. Vibratory bowl feeders also reduce labour, because they require very little human interaction.
We can develop vibratory bowl feeders from 6″ to 36″ in diameter. For optimum efficiency, we design and fabricate our bowl feeders simultaneously. Each bowl is custom built to meet the customer’s exact specifications regarding part configuration, feed rate and orientation.
To ensure the precise handling of almost any size and type of part — whether small or large, delicate or heavy duty — every SPM bowl feeder is designed and hand-crafted in-house using 11-gauge stainless steel. Type 304 stainless steel is standard, while Type 316 stainless steel is used in medical applications.
- • Hand-crafted in-house using 11-gauge stainless steel
- • Type 304 stainless steel standard
- • Type 316 stainless steel for medical applications
- • Suitable for small, large, delicate or heavy-duty parts
Automation
Industrial automation solutions that integrate conveyors, feeders, controls and fabricated assemblies into reliable production systems.
Assembly Automation
Automated assembly support using vibratory feeders, conveyors and purpose-built fixtures for consistent output.
Enquire Now →
Process & Line Automation
Conveyor-based line automation for transfer, accumulation, elevation and paced movement between stations.
Enquire Now →
Special Purpose Machines (SPM)
Custom SPM concepts integrating bowl feeders, chains, fabricated frames and controls for dedicated operations.
Enquire Now →Metal Fabrication
Metal fabrication covers processes that cut, shape, form and join metal into finished industrial parts and assemblies. We support fabrication needs from cutting and bending through welding and assembly.
What we cover
From flat material to finished assemblies, metal fabrication typically includes cutting, forming, machining and joining. The right mix depends on part geometry, material grade, volume and end-use environment.
Our fabrication offering aligns with industrial needs for frames, panels, guards, skids, brackets and custom structures used with conveyors, feeders and automation systems.
Enquire About FabricationCommon Metal Fabrication Processes
Cutting
Laser cutting, shearing and related cutting methods to split sheet and plate into accurate blanks and profiles.
Enquire Now →
Forming & Bending
Folding, bending, punching and stamping operations to shape flat material into channels, brackets and formed parts.
Enquire Now →
Welding & Joining
Welded assemblies and mechanical joining for frames, supports, guards and structural fabrications.
Enquire Now →
Machining
Material removal operations for holes, slots, surfaces and precision features on fabricated components.
Enquire Now →
Forging & Heavy Forming
Where strength and grain structure matter, heavier forming methods support demanding industrial parts.
Enquire Now →
Assembly & Finishing
Fit-up, assembly, surface preparation and finishing so parts are ready for installation or further integration.
Enquire Now →Process overview
- Casting — molten metal poured into a mold and solidified into shape
- Cutting — laser, shear, saw and related methods to size material
- Drawing / Extrusion — forcing metal through a die for profiles and shapes
- Folding / Bending — forming angles and contours in sheet and plate
- Forging — shaping metal using localized compressive force
- Machining — controlled material removal for accurate features
- Punching / Shearing / Stamping — high-volume sheet processes
- Welding — permanent joining of metal parts into assemblies
Process selection depends on geometry, material, quantity and performance requirements. Share your drawings for a practical recommendation.
Need a Custom Solution?
Tell us about your application. We can design and supply products tailored to your exact requirements.
Contact Us Today
